Model | R100 | R200 | R300 |
Wavelength（μm） | 10.6/9.3 | ||
Excited Frequency（MHz） | 81 | ||
Peak Power（W） | 250 | 400 | 600 |
Average Power（W） | 100 | 200 | 300 |
Duty Cycle Range（%） | 10-30 | 10-35 | 10-40 |
Beam Quality Factor | M2 ≤ 1.2 | ||
Beam Diameter（1/e2） | 7mm±0.5mm, at laser output optic | ||
Beam Divergence | < 3mrad | ||
Beam Ellipticity | < 1.2:1 | ||
Pointing Stability | < 0.25mrad(Half angle) | ||
Polarsation | Linear parallel to base | ||
Pulse Duration Range（μs） | 2～970 | ||
Repetition Rate Range（kHz） | 1～200 | ||
Power Instability（%） | <±3.5% | ||
Lifespan（h） | 20000 | ||
Coolant Power（kW） | > 3.2 | > 5.2 | > 7 |
Cooling Water Tube Diameter（mm） | 14 | ||
Tel：15950001005
E-mail：panxin@recilaser.com
WeChat：15950001005
Tel：15920098617
E-mail：huangkun@recilaser.com
WeChat：15920098617
1) High electro-optical conversion efficiency;
2) Good beam quality;
3) Compact structure;
4) High reliability and long service life.
