Model | HQ 60000 | HQ 80000 | HQ 120000 |
Output Power（W） | ≥ 60000 | ≥ 80000 | ≥ 120000 |
Central Wavelength（nm） | 1080 ± 5 | ||
Operating Mode | CW/Modulate | ||
Max Modulation Frequency（kHz） | 20 | ||
Power Instability | < 3% | ||
Red Laser power（mW） | > 0.5 | ||
Beam Delivery Optics | Q+ / LOE | ||
Output Fiber Diameter（μm） | 150（customizable） | 200（customizable） | |
Beam Quality BPP（mm*mrad） | ≤ 5.5 | ||
Delivery Fiber Length（m) | 30（customizable） | ||
Operating Voltage（VAC） | 380V ± 10%、50/60Hz | ||
Max Power Consumption（KW） | < 120 | ≤ 260 | ≤ 385 |
Control Model | Ext.RS232/Ext.AD | ||
Power Range（%） | 10～100 | ||
Ambient Temperature（℃） | 5～40 | ||
Ambient Humidity（%） | < 70 | ||
QBH Cooling Water Temperature（℃） | Room temperature | ||
Cooling Temperature（℃） | 25 ± 2 | ||
Cooling Flow（L/min） | ≥ 300 | ≥ 580 | ≥ 895 |
Size W x H x D（mm3） | 628 x 1278 x 1439 | 1120 x 1519 x 1439 | 1179 x 1704 x 1468 |
Weight（kg） | <750 | <1450 | <2150 |
Tel：138 1045 8641
E-mail：lishuming@recilaser.com
WeChat：138 1045 8641
Tel：13811421864
E-mail：pengbo@recilaser.com
WeChat：13811421864
Tel：13811183410
E-mail：wujuncheng@recilaser.com
WeChat：13811183410
Tel：15110159176
E-mail：wangaolan@recilaser.com
WeChat：15110159176
1) The laser module has high brightness, and the overall brightness after combining is leading in the country;
2) The spot energy distribution is diverse, adapting to various complex processing scenarios;
3) The average power is higher, and the thick plate cutting speed is faster and the processing quality is better;
4) The nonlinear effect suppression ratio is high, and the armored cable can be longer, which is suitable for large-format processing;
5) In terms of structure, high-power laser modules are used, the number of modules is reduced, and the product is highly integrated. Under the same power, it greatly saves space and Logistics cost; 6) Cabinet design can adapt to more complex environments, high temperature, high humidity, and complex electromagnetic environments.
